CCNA 1 v7 Modules 4 - 7: Ethernet CCNA v7.0 Exam Answers
Concepts Exam Answers
Dec 18, 2019 | Last Updated: Dec 20, 2022 | CCNA v7 Course #1 |
61 Comments
/Share Tweet Share Pin it
System Test Exam
Modules 1-3: Basic
Network Connectivity and
Communications Exam
Answers
Modules 4-7: Ethernet
Concepts Exam Answers
Modules 8-10:
Communicating Between
Networks Exam Answers
Modules 11 - 13: IP
Addressing Exam Answers
Modules 14 - 15: Network
Application Communications
Exam Answers
Modules 16 - 17: Building
and Securing a Small
Network Exam Answers
[PT Skills] Practice PT
Skills Assessment (PTSA)
[Final Skills] ITN Final
Skills Exam (PTSA)
TTNv7 Practice Final Exam
CCNA 1 v7 FINAL Exam
Answers
How to find: Press "Ctrl + F" in the browser and fill in
whatever wording is in the question to find that
question/answer. If the question is not here, find it in
Questions Bank
NOTE: If you have the new question on this test, please
comment Question and Multiple-Choice list in form
below this article. We will update answers for you in the
shortest time. Thank you! We truly value your
contribution to the website.
Empower Uki jiuian Chl!di«nri Future
Help war-impacted
kids access education
7.00)-
im
( Vci jon
Jo:
Introduction to Networks
Modules 4 - 7 : Ethernet icepts
1. What is the purpose of the OSI
• controlling access to media
* transmitting bits across the local media
• performing error detection on received frames
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 2/50

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
• exchanging frames between nodes over physical network
media
2. Why are two strands of fiber used for a single fiber optic
connection?
• The two strands allow the data to travel for longer distances
without degrading.
• They prevent crosstalk from causing interference on the
connection.
’ They increase the speed at which the data can travel.
• They allow for full-duplex connectivity.
3. Which characteristic describes crosstalk?
• the distortion of the network signal from fluorescent lighting
• the distortion of the transmitted messages from signals
carried in adjacent wires
• the weakening of the network signal over long cable lengths
• the loss of wireless signal over excessive distance from the
access point
4. Which procedure is used to reduce the effect of crosstalk
in copper cables? DONATE
TODAY
MriyaAidxa n
" 1AYOUR CONNECTIONryfl
W I T H IT COMMUNITY
_________
Join IT Cluster in the Cloud
requiring proper grounding c
twisting opposing circuit wir
wrapping the bundle of wires bidding
Related Posts
4.7.4 Module Quiz - Physical Layer
(Answers)
5.3.2 Module Quiz - Number Systems
(Answers)
12.5.8 Check Your Understanding -
Dynamic Addressing for IPv6 GUAs
Answers
CCNA 1 v7.0 Curriculum: Module 16 -
Network Security Fundamentals
7.2.7 Lab - View Network Device
MAC Addresses (Answers)
■ designing a cable infrastructure to avoid crosstalk
interference
* avoiding sharp bends during installation
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 3/50

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
11.6.6 Lab - Calculate IPv4 Subnets
(Answers)
2.9.2 Lab - Basic Switch and End
Device Configuration (Answers)
7.1.5 Check Your Understanding -
Ethernet Switching Answers
12.9.4 Module Quiz - IPv6 Addressing
(Answers)
5.1.4 Check Your Understanding -
Binary Number System Answers
5. Match the situation with the appropriate use of network
media.
AD
I
6. A network administrator is measuring the transfer of bits
across the company backbone for a mission critical financial
application. The administrator notices that the network
throughput appears lower than the bandwidth expected.
Which three factors could influence the differences in
throughput? (Choose three.)
* the amount of traffic that is currently crossing the
network
’ the sophistication of the encapsulation method applied to the
data
• the type of traffic that is crossing the network
• the latency that is created by the number of network
devices that the data is crossing
■ the bandwidth of the WAN connection to the Internet
* the reliability of the gigabit Ethernet infrastructure of the
backbone
Recent Comments
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 4/50

5/18/24, 5:27 AM CCNA I v7 Modules 4-7: Ethernet Concepts Exam Answers
Miguel on Network Security
(Versionl .0) - Final Exam Answers
Full
viva on CCNA 1 v7 Modules 11-13:
IP Addressing Exam Answers Full
xeno on Endpoint Security: My
Knowledge Check Answers
DanCooper on ENSA (Version 7.00)
Final PT Skills Assessment Exam
(PTSA) Answers
Anandaraj on CCNA 1 v7.0 Final
Exam Answers Full - Introduction to
Networks
41Df o u n d a t i o n
Determined
and effective
Support Ukrainian volunteers
in making a bigger impact
Explanation: Throughput usually does not match the
specified bandwidth of physical links due to multiple factors.
These factors include, the amount of traffic, type of traffic,
and latency created by the network devices the data has to
cross.
7. What are two characteristics of fiber-optic cable? (Choose
two.)
* It is not affected by EMI or RFI.
■ Each pair of cables is wrapped in metallic foil.
* It combines the technique of cancellation, shielding, and
twisting to protect data.
* It typically contains 4 pairs of fiber-optic wires.
■ It is more expensive than UTP cabling is.
Explanation: Fiber-optic cabling supports higher bandwidth
than UTP for longer distances. Fiber is immune to EMI and
RFI, but costs more, requires more skill to install, and
requires more safety precaution
8. What is a primaiy role of the P
data on the network?
ansmitting
• create the signals that represent the bits in each frame
on to the media
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 5/50

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
* provide physical addressing to the devices
■ determine the path packets take through the network
* control data access to the media
Explanation: The OSI physical layer provides the means to
transport the bits that make up a frame across the network
media. This layer accepts a complete frame from the data
link layer and encodes it as a series of signals that are
transmitted to the local media.
9. With the use of unshielded twisted-pair copper wire in a
network, what causes crosstalk within the cable pairs?
Invest In rtsilkinte Jiowl
DONATE
TODAY
MriyaAid.ca n
• the magnetic field around the adjacent pairs of wire
• the use of braided wire to shield the adjacent wire pairs
• the reflection of the electrical wave back from the far end of
the cable
’ the collision caused by two nodes trying to use the media
simultaneously
Explanation: Crosstalk is a 0
that occurs when signal transm
with another wire. When curre
iterference
e interferes
a wire a
magnetic field is produced. Th
interface the signal earned in the adjacent wire.
etic field will
10. Refer to the graphic. What type of cabling is shown?
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 6/50

Loading page 6...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
• STP
• UTP
• coax
• fiber
Explanation: Network cabling include different types of
cables:
• UTP cable consists of four pairs of color-coded wires
that have been twisted together and then encased in a
flexible plastic sheath.
• STP cable uses four pairs of wires, each wrapped in a
foil shield, which are then wrapped in an overall metallic
braid or foil.
* Coaxial cable uses a copper conductor and a layer of
flexible plastic insulation surrounds the copper
conductor.
* Fiber cable is a flexible, extremely thin, transparent
strand of glass surrounded by plastic insulation.
11. In addition to the cable length, what two factors could
interfere with the communication carried over UTP cables?
(Choose two.)
* crosstalk
bandwidth
size of the network
signal modulation technique
electromagnetic interference
Explanation: Copper media is widely used in network
communications. However, copper media is limited by
distance and signal interference. Data is transmitted on
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 7/50

Loading page 7...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
copper cables as electrical pulses. The electrical pulses are
susceptible to interference from two sources:
* Electromagnetic interference (EMI) or radio
frequency interference (RFI) - EMI and RFI signals
can distort and corrupt the data signals being carried by
copper media.
■ Crosstalk - Crosstalk is a disturbance caused by the
electric or magnetic fields of a signal on one wire
interfering with the signal in an adjacent wire.
12. Refer to the graphic. What type of cabling is shown?
* STP
■ UTP
■ coax
• fiber
13. Which two devices commonly affect wireless networks?
(Choose two.)
* Blu-ray players
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 8/50

Loading page 8...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
• home theaters
■ cordless phones
• microwaves
• incandescent light bulbs
• external hard drives
Explanation: Radio Frequency Interference (RFI) is the
interference that is caused by radio transmitters and other
devices that are transmitting in the same frequency.
14. Which two statements describe the services provided by
the data link layer? (Choose two.)
It defines the end-to-end delivery addressing scheme.
It maintains the path between the source and destination
devices during the data transmission.
It manages the access of frames to the network media.
It provides reliable delivery through link establishment and
flow control.
It ensures that application data will be transmitted according
to the prioritization.
It packages various Layer 3 PDUs into a frame format
that is compatible with the network interface.
Explanation: The data link layer is divided into two sub
layers, namely Logical Link Control (LLC) and Media Access
Control (MAC). LLC forms a frame from the network layer
PDU into a format that conforms to the requirements of the
network interface and media. A network layer PDU might be
for IPv4 or IPv6. The MAC sub layer defines the media
access processes performed by the hardware. It manages
the frame access to the network media according to the
physical signaling requirements
wireless, etc.)
iber optic,
15. What is the function of the C
FCS field of a frame?
und in the
' to verify the integrity of the received frame
" to verify the physical address in the frame
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 9/50

Loading page 9...

5/18/24, 5:27 AM CCNA I v7 Modules 4-7: Ethernet Concepts Exam Answers
* to verify the logical address in the frame
■ to compute the checksum header for the data field in the
frame
Explanation: The CRC value in the FCS field of the
received frame is compared to the computed CRC value of
that frame, in order to verify the integrity of the frame. If the
two values do not match, then the frame is discarded.
16. What is contained in the trailer of a data-link frame?
* logical address
* physical address
■ data
■ error detection
Explanation: The trailer in a data-link frame contains error
detection information that is pertinent to the frame included
in the FCS field. The header contains control information,
such as the addressing, while the area that is indicated by
the word "data" includes the data, transport layer PDU, and
the IP header.
17. Which statement describes a characteristic of the frame
header fields of the data link layer?
rn p o w e r U k r a i n i a n C h i l d r e n ' s F u t u r e
Help W a r - I m p a c t e d Kids Access Educa
•8&UKRAINE
=- FRIENDS
61
They all include the flow con
Ethernet frame header fields
connection fields.
am Lay source and
They vary depending on prot
destination addresses.
They include information on user applications.
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 10/50

Loading page 10...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
Explanation: All data link layer protocols encapsulate the
Layer 3 PDU within the data field of the frame. However, the
structure of the frame and the fields that are contained in the
header vary according to the protocol. Different data link
layer protocols may use different fields, like priority/quality of
service, logical connection control, physical link control, flow
control, and congestion control.
18. A network team is comparing physical WAN topologies
for connecting remote sites to a headquarters building.
Which topology provides high availability and connects
some, but not all, remote sites?
• mesh
• partial mesh
• hub and spoke
• point-to-point
Explanation: Partial mesh topologies provide high
availability by interconnecting multiple remote sites, but do
not require a connection between all remote sites. A mesh
topology requires point-to-point links with every system
being connected to every other system. A point-to-point
topology is where each device is connected to one other
device. A hub and spoke uses a central device in a star
topology that connects to other point-to-point devices.
19. Which two fields or features does Ethernet examine to
determine if a received frame is passed to the data link layer
or discarded by the NIC? (Choose two.)
* auto-MDIX
* CEF
* Frame Check Sequence
■ minimum frame size
’ source MAC address
Explanation: An Ethernet frame is not processed and is
discarded if it is smaller than the minimum (64 bytes) or if the
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 11/50

Loading page 11...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
calculated frame check sequence (FCS) value does not
match the received FCS value. Auto-MDIX (automatic
medium-dependent interface crossover) is Layer 1
technology that detects cable straight-through or crossover
types. The source MAC address is not used to determine
how the frame is received. CEF (Cisco Express Forwarding)
is a technology used to expedite Layer 3 switching.
20. Which media communication type does not require media
arbitration in the data link layer?
’ deterministic
* half-duplex
* full-duplex
* controlled access
Explanation: Half-duplex communication occurs when both
devices can both transmit and receive on the medium but
cannot do so simultaneously. Full-duplex communication
occurs when both devices can transmit and receive on the
medium at the same time and therefore does not require
media arbitration. Half-duplex communication is typically
contention-based, whereas controlled (deterministic) access
is applied in technologies where devices take turns to
access the medium.
21. Which statement describes an extended star topology?
AD
a IDf d fl <i 0 t i o n
Support Ukra
in making a bigger impoci
Deter
and e
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 12/50

Loading page 12...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
* End devices connect to a central intermediate device,
which in turn connects to other central intermediate
devices.
* End devices are connected together by a bus and each bus
connects to a central intermediate device.
■ Each end system is connected to its respective neighbor via
an intermediate device.
* All end and intermediate devices are connected in a chain to
each other.
Explanation: In an extended star topology, central
intermediate devices interconnect other star topologies.
22. What is a characteristic of the LLC sublayer?
• It provides the logical addressing required that identifies the
device.
• It provides delimitation of data according to the physical
signaling requirements of the medium.
• It places information in the frame allowing multiple Layer
3 protocols to use the same network interface and
media.
■ It defines software processes that provide services to the
physical layer.
Explanation: The Logical Link Control (LLC) defines the
software processes that provide services to the network
layer protocols. The information is placed by LLC in the
frame and identifies which network layer protocol is being
used for the frame. This information allows multiple Layer 3
protocols, such as IPv4 and IPv6, to utilize the same network
interface and media.
61
23. What are three ways that medi
networking? (Choose three.)
is used in
Ethernet utilizes CSMA/CD.
• Media access control provides placement of data frames
onto the media.
■ Contention-based access is also known as deterministic.
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 13/50

Loading page 13...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
* 802.11 utilizes CSMA/CD.
■ Data link layer protocols define the rules for access to
different media.
* Networks with controlled access have reduced performance
due to data collisions.
Explanation: Wired Ethernet networks use CSMA/CD for
media access control. IEEE 802.11 wireless networks use
CSMA/CA, a similar method. Media access control defines
the way data frames get placed on the media. The controlled
access method is deterministic, not a contention-based
access to networks. Because each device has its own time
to use the medium, controlled access networks such as
legacy Token Ring do not have collisions.
24. During the encapsulation process, what occurs at the
data link layer for a PC connected to an Ethernet network?
• An IP address is added.
• The logical address is added.
• The physical address is added.
• The process port number is added.
Explanation: The Ethernet frame includes the source and
destination physical address. The trailer includes a CRC
value in the Frame Check Sequence field to allow the
receiving device to determine if the frame has been changed
(has errors) during the transmission.
25. What three items are contained in an Ethernet header and
trailer? (Choose three.)
* source IP address
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 14/50

Loading page 14...

5/18/24, 5:27 AM CCNA 1 v7 Modules 4-7: Ethernet Concepts Exam Answers
* source MAC address
■ destination IP address
’ destination MAC address
* error-checking information
Explanation: Layer 2 headers contain the following:
* Frame start and stop indicator flags at the beginning
and end of a frame
* Addressing - for Ethernet networks this part of the
header contains source and destination MAC addresses
■ Type field to indicate what Layer 3 protocol is being
used
* Error detection to determine if the frame arrived without
error
26. What type of communication rule would best describe
CSMA/CD?
• access method
* flow control
* message encapsulation
• message encoding
Explanation: Carrier sense multiple access collision
detection (CSMA/CD) is the access method used with
Ethernet. The access method rule of communication dictates
how a network device is able to place a signal on the carrier.
CSMA/CD dictates those rules on an Ethernet network and
CSMA/CA dictates those rules on an 802.11 wireless LAN.
27. Which three basic parts are common to all frame types
supported by the data link layer? (
’ header
• type field
• MTU size
’ data
■ trailer
* CRC value
https://itexamanswers.net/ccna-l-v7-modules-4-7-ethernet-concepts-exam-answers.html 15/50

Loading page 15...

Ethernet Concepts Exam Answers

Study Now!

Document Details

Related Documents

Dump4Cisco CCNA CyberOps Associate 200-201

CCNA 1 - Introduction to Networks

CCNA 1 v7

CCNA 1 v7

9TUT CCNA Exam 102 Questions

CCNA Module Quiz Number Systems & IP Addressing

CCNA 4 Pretest Part 2

CCNA Week 1 Networks Basic Configuration

Week 4 Security Concepts CCNA

CCNA Exam Review Fundamentals12 Stamped

Company

Explore

Study Tools
